Technology
Technical Details
Frameset
Frame:
SCOR 4060 Full Carbon Frame | Lower-Link Driven Instant Center Linkage | 140 / 160mm Rear Wheel Travel | Fully Guided Internal Cable Routing | Stash Box | Boost 148 | SRAM UDH | Lower ISCG 05 Mount / Chainguide
Fork:
Fox 38 Factory GRIP2 | 170mm Travel | 44mm Rake
Suspension
Front Suspension:
Fox 38 Factory GRIP2 | 170mm Travel | 44mm Rake
Rear Suspension:
Fox Float X2 Factory | 205 x 62.5mm Trunnion
Cockpit
Stem:
Burgtec Enduro MK3 | 31.8mm Bar Bore | 35mm Length | 0° Angle
Handlebar:
SCOR Carbon Bar | 31.8mm Clamp | 800mm Wide | 20mm Rise | 5° Upsweep | 7.5° Backsweep
Grips:
Burgtec Bartender Pro
Seat
Seatpost:
Bikeyoke Divine | S 125mm | M 160mm | L / XL 185mm Travel | Triggy Alpha lever
Saddle:
WTB Silverado Medium Titanium
Drivetrain
Crankset:
SRAM GX Eagle Carbon Lunar | 170mm Length
Chainrings:
32T
Cassette:
SRAM GX XG-1275 Eagle
Cassette Size:
10-52T
Chain:
SRAM GX Eagle
Rear Derailleur:
SRAM GX Eagle
Shifters:
SRAM GX Eagle Trigger
Gears:
1 x 12
Bottom Bracket:
DUB Interface
Brakes
Brake Levers / Calipers:
SRAM Code RSC
Rotors:
SRAM Centerline | 6-Bolt
Rotor Size (F/R):
200mm
Wheels
Rims:
DT Swiss EX 1700 SPLINE | 30mm Internal Width | Tubeless ready
Hubs (F/R):
DT Swiss 350 | Ratchet SL Freehub | Straightpull Spoke Interface | Boost spacing
Tires:
Maxxis Assegai 29 x 2.5" 3C MaxxGrip Exo+ TR (F) | Maxxis Dissector 29 x 2.4" 3C MaxxTerra DD TR (R)
Tubeless Information:
Tubeless Ready Rims | Tubetype Tires
Additional Information
Tire Clearance:
Width: 64mm | Diameter: 750mm
ASTM Classification:
Level 4
System Weight Limit:
120kg
